Welcome to HVAC Shop Drawings LLC
Our goal is to maintain a long-lasting relationship with our clients based on exceptional HVAC, Piping & Plumbing Shop Drawings. We provide the best HVAC, Piping & Plumbing Shop Drawings that you can manufacture from at the lowest price in the field.
IF YOU WANT A FREE QUOTE YOU MUST ANSWER THESE 3 SIMPLE QUESTION.
- 2D or 3D BIM
- Scope of work: Ductwork Hvac pipe or Plumbing.
- SMACNA fabrication drawing or just Coordination?
What we do
HVAC Plumbing Shop Drawings and As-Builts
Among other disciplines, We are experienced in developing a complete and coordinated building engineering package
1.Full CAD services
2.Development of design drawings (conceptual, partial, phasing, complete)
3.Development of a complete bid specification package
4.Management Xrefs
5.Equipment Schedules
Offer Service
1. All HVAC shop drawings will show the routing of ductwork closely following the contract drawing. The duct will be detailed to miss structure, due to the ability to draw in 3D.
2. All HVAC Shop Drawing Ductwork will be drawn to match your shop standards. Ensuring the drawings are as accurate as possible.
3.Dimensions showing ductwork and gridline relationship. (or wall relationship as required)
4.All HVAC Shop Drawing ductwork will show size, length of each piece, top and bottom elevations. Fittings will show throat lengths, amount of rise or fall and amount of offset.
5.Riser duct will be shown if needed. Shaft duct will be detailed.
6.Exact placement of VAVs, TAUs, EFs and AC units showing access required.
7.Pad drawings of Air Handling Units if required.
8. Placement of registers and grilles.
9.Drawings will show your logo (if provided in drawing format ), company name, address and phone numbers.
